Fox G-Maxx 215 kWh All-in-One Battery Storage System
+7
+6
+5
+4
+3
+2

Fox G-Maxx 215 kWh All-in-One Battery Storage System

48.990,00€
NEU!!
Excl. shipping
Lieferzeit: 2 Wochen
In stock
1
Share this product with your friends
ShareSharePin it
Fox G-Maxx 215 kWh All-in-One Battery Storage System
Product Details
Marke: FoxESS
Dimension:: 1000 x 1500 x 2200 mm
Weight:: 2500 Kg

Fox G-Maxx 215 kWh All-in-One Battery Storage System – Efficiency and Reliability for Your Energy Needs

The Fox G-Maxx 215 kWh is a state-of-the-art, all-in-one battery storage system specifically designed for commercial and industrial applications. With an impressive storage capacity of 215 kWh and a power output of 100 kW at a 2-hour discharge rate, it offers a powerful solution to optimize your energy costs and promote sustainability.


Key Features of the Fox G-Maxx 215 kWh

✔ High Performance and Capacity

  • Storage Capacity: 215 kWh
  • Power Output: 100 kW at a 2-hour discharge rate
  • Battery Voltage: 768 V

✔ Flexibility through Parallel Installation

  • Parallel Operation: Up to 10 systems can be operated in parallel (maximum 5 in off-grid mode).
  • Island/Off-Grid Mode: Supports black start functions for maximum independence from the public grid.

✔ Intelligent Energy Management

  • Multiple Operating Modes: Peak shaving, load shedding, PV storage energy control, and frequency control.
  • Cloud Connectivity: Business data can be sent to the Fox ESS Cloud via Wi-Fi, 4G, or 5G for real-time monitoring and optimization.

✔ Robust Design and Safety

  • IP54 Protection Class: Ensures protection against dust and splashing water.
  • Temperature Tolerance: Operating temperature range of -20°C to 50°C (power derating occurs at temperatures >45°C).
  • Separate Battery Cabinet: Equipped with liquid cooling for optimal temperature regulation and minimal power loss.

✔ Compact and User-Friendly Design

  • Dimensions: 1000 x 1500 x 2200 mm (W x D x H)
  • Weight: 2,500 kg
  • Easy Installation: The integrated design allows for quick installation and maintenance.

Technical Specifications Overview

Parameter
Details
Storage Capacity
215 kWh
Power Output
100 kW (2-hour discharge)
Battery Voltage
768 V
Operating Temperature
-20°C to 50°C (>45°C power derating)
Protection Class
IP54
Cooling
Separate battery cabinet with liquid cooling
Dimensions (W x D x H)
1000 x 1500 x 2200 mm
Weight
2,500 kg
Parallel Operation
Up to 10 systems (5x off-grid)
Connectivity
Wi-Fi, 4G, 5G

Detailed Benefits

✔ Maximum Energy Efficiency

  • Thanks to integrated temperature regulation and frequency variation, power loss is minimized, enhancing system efficiency.

✔ Reliable Safety

  • Advanced safety features such as liquid cooling and the IP54 protection class ensure safe and long-lasting operation.

✔ Scalability

  • By operating multiple systems in parallel, you can flexibly adjust the capacity and performance to meet your needs.

✔ Future-Proof

  • The integration of cutting-edge technologies and cloud connectivity makes the system ready for future expansions and requirements.

Why Choose the Fox G-Maxx 215 kWh?

The Fox G-Maxx 215 kWh combines high performance, intelligent control, and robust safety in a compact system. Whether for commercial or industrial applications – this battery storage system offers maximum flexibility, efficiency, and reliability. At the same time, it is a sustainable investment that reduces your energy costs and increases your independence from the public grid.


Order Now and Boost Your Energy Efficiency!

Visit our online shop and secure the Fox G-Maxx 215 kWh at an attractive price! If you have any questions, we are always available to assist you. Take the first step towards intelligent energy storage.


For More Information or Support

Contact us today! Our team is ready to provide personalized advice and tailored solutions.


Note:

All technical data and specifications are based on the latest technology. Technical changes and errors are subject to change without notice.


Installation Notes

  • Professional Installation Required: To avoid warranty issues, the unit must be installed by a certified installer.
  • Site Preparation: The installation site must be prepared for unloading and placing the unit (e.g., concrete slab).
  • Final Setup: A professional installer must be present at the unloading site to unpack and set up the unit.


Information obligation according to § 18 paragraph 1 of the Battery Act

If you have decided in favour of a battery storage system or a battery or rechargeable battery-operated product from our range, we are obliged to inform you of the following:
Batteries and rechargeable batteries may not be disposed of with household waste, but you are legally obliged to return used batteries and rechargeable batteries. Batteries may contain harmful substances that can damage the environment or your health if they are not stored or disposed of properly. However, they also contain important raw materials such as iron, zinc, manganese or nickel and can be recycled. You can either send the batteries back to us after use or return them free of charge in the immediate vicinity (e.g. retail outlets, municipal recycling centres or our warehouse). Disposal at points of sale is limited to the usual quantities for end users and to used batteries that the distributor carries or has carried in its range as a supplier.
The symbol with the crossed-out wheelie bin means that you must not dispose of batteries and rechargeable batteries in household waste. Below this symbol you will also find the following symbols with the following meanings
Hg: Battery contains mercury
Cd: Battery contains cadmium
Pb: Battery contains lead
After use, batteries can be returned free of charge to us in Hagen, to retailers or to local authority recycling centres.
We would like to point out that you as the end user are legally obliged to return used batteries.
All batteries are labelled with the crossed-out dustbin symbol.
If certain limit values are exceeded, they are also labelled with the chemical symbols of the metals (Hg= battery contains more than 0.0005% mercury by mass, Cd= battery contains more than 0.002% cadmium by mass, Pb= battery contains more than 0.004% lead by mass).
